A Container Flatbed Trailer known as a flatbed trailer, is used to transport products with specific requirements. Flatbeds became increasingly rare in the 1980s as most cargo was transported on pallets or containers. It is significantly simpler to load and unload because of the flat design of the body.

PARAMETER of 40FT Flatbed Semi-trailer

Feature: Carry 1X20FT、1X40FT、or 2X20FT container

Dimension(L*W*H): 12420*2500*1570mm

Main frame: Heavy duty and extra durability design; Opting for high tensible low carbon alloy Q345B steel; I beam welded by automotive arc-submerge process

Model: XMS9380TP

No. of axle: 3

Payload(kgs): 40000

Tare weight(kgs): 6800

Kingpin: Bolt-in type 3.5” or 2”

Landing gear: Two-speed manual operation 19”

Tire size: 315/80R22.5 (13 sets)

Rim size: 9.00*22.5(13 sets)

Axle: 3 Axle, 13 Tons

Suspension Spring Germany suspension with 12pcs of leaf spring

Brake system: Dual line with Re-6 emergency relay valve, T30/30 air chamber, 46L air tank

Electric system: One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable

Container locks 12(for 1x20GP,2X20GP,1X40HQ)

Painting: Two coat of anti-corrosion prime; one coat of finish painting

Accessory: One tool box; one set of standard tool

Flatbed trailer maintenance

Structural Features: Flatbed trailers consist of a solid platform chassis and tires with no fences or side panels. Platforms are usually made of steel and have sufficient strength and stability to carry a variety of cargo.

Load Capacity: Its load capacity varies depending on size, design and materials. Generally speaking, flatbed trailers can carry heavy cargo, and the load capacity usually ranges from 20 tons to 40 tons.

Versatility: Suitable for transporting various types of cargo, including large machinery and equipment, construction materials, containers and other large cargo. There are no fences or side panels on a flatbed trailer, making it easy to load and unload cargo.

Usage scenarios: Flatbed trailers are widely used in the logistics and transportation industries. They play an important role on construction sites, ports, warehousing facilities and manufacturing industries. Flatbed trailers are also commonly used for long-distance transportation and international freight, and are especially suitable for transporting over-long, over-wide, and over-height cargo.

Safety and Stability: During transportation, cargo must be properly secured and lashed to ensure there is no risk of shifting or overturning. Drivers need to have professional skills and experience to ensure the safe operation of flatbed trailers in various road conditions.
