As a driver or people who work with trucks, it's important that you know something about truck tires in case you need to. Here's some information about truck tires.

Tyre performance

First, for example, 900-20 tires, the speed of 60KM/H, the tire deformation of each part up to 20,000 times/hour, transmit more than 90 horsepower power,surface temperature can be 70 ~ 100℃, buffer layer can reach more than 100℃. It is not difficult for us to imagine a speed of over 100KM/H. In short, the conditions of use on the tire performance requirements are very harsh.

Performance requirements for tyres include:

1. Economy (long service life, wear resistance and fuel saving).

2. Driving safety (good grip of tire is required).

3. Comfort (low noise, high buffering).

4. Strong carrying capacity (overload).

5. High driving speed.

6. Requirements of climate (cold tolerance in high latitudes and heat tolerance in low latitudes).

7. Requirements for road conditions (good pavement resistance to fatigue, low heat generation, heat resistance and low noise).

(Poor pavement resistance to cutting, pricking and tearing).

8. Low cost requirements.

Tires are very difficult to meet the above requirements, because some requirements are contradictory, such as good grip tire, wear resistance is good, but heat generation will be high. SUNSKY trailer focus on tire's different performance to design structure,in order to achieve a better balance.

General knowledge of tires

A set of tubeless tires includes an outer tire, a inner tire, and a pad.Inner tire has natural rubber tubules and butyl rubber tubules, and outer tire has bias tubules and semi-steel radial tubules. Most radial tires are tubeless tires.The outer tire is composed of rubber and skeleton materials. The main function of the skeleton material is to bear the internal and external stress of the tire and maintain the shape of the tire. The requirements for skeleton materials are: high strength, high modulus, good heat resistance, good fatigue resistance, stable size, good adhesion with rubber, cheap price, small specific gravity, etc.

Introduction of tire components

1) Tire crown

Because of direct contact with the ground, tire crown should has good performance of abrasion resistance, tear resistance, pricking resistance, good grip.

2) Tire shoulder

The stress concentration part,tire shoulder rubber is thicker, heat dissipation is poor, so the requirement has higher strength, lower heat generation, faster heat dissipation, heat resistance, high constant elongation.

3) Tire side

Protect tire body,requires resistance to flexure, cracking and aging.

4) Tire body

The main parts of the tire bearing, the requirements of dimensional stability, fatigue resistance, impact resistance.

5) Buffer layer

Strengthen the strength of the tire crown, improve the impact resistance and puncture resistance, and protect the tire body.

6) Tire tracks

Fix the tire firmly to the rim.

7) Oil skin glue

Protect the tire body and inner tire.

These are the parts of the bias tire, the radial tire has belt layer, which like the track used to carry most of the force of the tire.

Use and maintenance of truck tires

Storage:

1. The tires should be stored in the warehouse to avoid the sun and rain.

2. Tyres should not be mixed with oils, inflammables and chemical corrosives.

3. The tire should be away from heat sources, power generation equipment and places that produce ozone.

4. Tires should be used in the order of first in, first out in production and warehousing, and the storage period should not exceed three years.

Shipment:

Forklift fork is not allowed to be directly inserted into the central hole of the tire ring to lift the tire, so as not to damage the tire ring.

The selection:

According to the use of vehicles,choose suitable tire type, such as radial tires, oblique tires, engineering tires, agricultural tires, etc.

Assembly:

1. Tires must be assembled on the specified models and rims. Special tools and instruments should be used to install and remove tires.

2. The same axle shall be equipped with the same specification,structure, pattern and grade tires.

3. Bias tires and radial tires cannot be mixed.

4. Pay attention to the directional mounting to the tire.

5. Tires with anti-skid chains should be installed symmetrically and removed immediately when not in use.

Decorative pattern:

1. Choose the pattern type according to the service conditions and vehicle types, such as transverse, longitudinal, mixed and off-road patterns.

2. Tread pattern grinding to wear mark should stop using.

Air pressure:

1. The tire shall be inflated according to the national standard stipulated in the "pressure load corresponding meter".

2. During using the tire, the internal pressure must be kept normal. When running for a long time or working, the tire pressure should be checked regularly.When stopping for a long time, the front and rear axle must be set up.

3. Tires with high air pressure are easy to explode.Low air pressure tires easily deformation and crush.

4. When tire twins are installed together, the air pressure of the two tyres should be the same.

Load:

1. The tire load should be in line with the current national standard provisions. Overload is strictly prohibited.

2. The loading of vehicles should be evenly distributed to avoid uneven grind on the tread of tires.

3. High grade and heavy load tires should not exceed the speed limit. The reinforced tire can increase the load appropriately according to the design standard.

Speed:

1. All kinds of tires have different speed limits. Overspeed will cause early damage of tires.

2. If the road situation is not good, don't drive too fast. Try to reduce the sharp brakes and sharp turns to avoid the impact of tires on sharp objects.

3. Drive at high speed. Tire temperature is too high, to take timely measures to prevent the explosion.

4. High speed tire and rim assembly must be dynamic balance detected, configurated and calibrated.

Vehicle condition:

1. The front wheel and beam of the vehicle should be frequently detected and adjusted, otherwise it will cause partial tire grinding and early damage.

2. Do not use rusty or missized rims, which will cause tire toe abrasion.

Transposition:

1. The tires should be changed regularly.

2. The truck trailer tire and construction machinery tire shall be maintained for the first grade when combined with the vehicle. If necessary (such as serious unilateral grinding), the truck shall be shifted once.Conduct secondary maintenance in combination with vehicle secondary maintenance, find problems and deal with them timely.

Inner tire:

1. Use inner tires according to the size of the tire.

2. Butyl inner tire is with high temperature resistant, good air tightness, high-speed tires should choose butyl inner tires.

3. Separate storage of inner tire should be filled with appropriate amount of air, and should not be folded or stacked. If not separate storage, it should be placed in the outer tire and inflated appropriately.

Renovation:

1. The tire should be refurbished and repaired until the grinding mark or damage occurs.

2 Ensure safety. Refurbished tyres should not be used as steering wheels (front wheels).

All steel radial tire profile

From the perspective of the development history of tire technology, it is a major change from simple solid tire to pneumatic tire, and from bias structure tire to radial structure tire is a major change of pneumatic tire.

Since Michelin invented the radial tire in 1948, it has developed rapidly due to its excellent performance. At present, the world radial tire has accounted for about 90 percent of the tire production, China's radial tire  annual growth rate up to 40 percent from 1990 to 2000, the future will continue to grow at 10 percent to 12 percent per year.

The superiority of radial tire

1. Low rolling resistance, saving fuel.

Radial tire rolling resistance is generally lower than bias tires in 20%~30%, fuel saving in 6.8% ~ 11.3%.

2. High speed safety, low heat generation.

In the same conditions, the driving temperature of bias tire is generally 30℃ higher than that of radial tire.

3. Wear resistance, thorn resistance and durability.

The abrasion life of radial tire is generally 75%~120% higher than that of bias tire.

4. Shock absorption, comfort and low noise.

5. Good operation and stability.

The starting speed of radial tire is 3.5%~15% faster than that of bias tire. The acceleration effect is 30% faster.Braking efficiency is about 10% higher.

These are just the tip of the iceberg of tire knowledge, there are more information you can go to understand, also welcome to contact us for more information.
